Tool 94252 Pre-tensioning jack for elastic bolt to exhaust valve cage
1 Piston 7 Adapter piece
2 Back-up ring
O-ring
Sealing ring
8 Closing valve
3 9 Control pin
4 Cylinder
5 Back-up ring
O-ring
Sealing ring
6
94252−KJ K
it with back-up and O-rings
for pre-tensioning J
ack
1
2
3
5
6
MAX. STROKE 11 MM
94252−KJ
4
WCH00977
7
8
9
2013
Hydraulic Pre-tensioning Jacks: Storing, Servicing and Maintenance
