Winix ZERO+ User Manual


English ZERO+ WiFi
FILTER CARE
3. Filter Assembly and Replacement
Filters should be re-installed in the reverse order of their removal.
ŵ
Insert the replacement
3 True HEPA filter with Cleancel™ (rear)
2 CD Carbon filter (middle)
ˍ
Remove the protective plastic wrap from
new filters. Operating the unit without
removing the protective plastic wrap
may cause abnormal noise, deformation,
or fire as a result of overheating.
Carbon
lter
True HEPA
lter with
Cleancel™
Ŷ
Insert the 1 Pre-filter (front)
ˍ
To install the pre-filter, insert bottom
tabs into the slots on either side of
the lower part of the unit, then rotate
upward to insert the upper tabs into
the slots at the top part of the unit until
both sides audibly click into place.
ŷ
Replace the front panel by first inserting
the latch at the bottom edge into the
base of the unit, then rotate the panel
upward toward the top of the unit until it
magnetically snaps closed.
Ÿ
After replacing the filters, turn the power
back on and then use a thin object, such as
a paper clip, to press the RESET switch for
5seconds.

Winix ZERO+ Specifications

General

Timer	Yes
Noise level	55 dB
Certification	CE, RoHS, WEEE
Air purify rate	- m³/h
Number of speeds	4
Suitable for room area up to	40 m²
Sustainability certificates	ENERGY STAR
Filtering capability	Cigarette smoke, Fine dust, Pollen
Number of filter stages	5
Product color	Grey, White
Built-in display	No
Power consumption (max)	90 W

Weight and Dimensions

Depth	245 mm
Width	415 mm
Height	600 mm
Weight	8500 g
