Page 35
Winkhaus STV
Operating Manual EAV 0124653 0505
Subject to technical changes
Winkhaus STV GmbH & Co. KG · Berkeser Str. 6 · D-98617 Meiningen · Germany · www.winkhaus.de · stv@winkhaus.de
7 Technical specifications
7.1. Antenna/Reader Unit
Dimensions (antenna): antenna housing: 90 x 90 x 13 mm
[3.543 x 3.543 x 0.512“], for exposed
installation, cable is permanently installed
Dimensions (reader): 45 x 45 x 22 mm [1.772 x 1.772 x 0.866“]
Reading distance: between 0 and 8 cm [0 - 3.150“]
(depending on the installation environment)
Signalization: piezo-buzzer
Data memory: max. 250 transponders
Reader technique: Prox reader
Power consumption: max. 100 mA
Voltage: 12 V AC/DC
7.2. Wireless remote control
Receiver type: Superheterodyne
Modulation: AM/ASK
Frequency: 433.92 MHz
Number of code combinations: 2 to the power of 64 („Rolling Code“)
Frequency of the local oscillator: 6.6128 MHz
Intermediate frequency: 10.7 MHz
Sensitivity (to receive signals): -115 dB
Input impedance: 50 ohm
Maximum memory capacity: max. 85 keys
Power supply: 12/24 V AC/DC
Closed-circuit current: 10 mA
On-load current: 23 mA
Number of relays: 1 (NO-NC), output 24 V A
Dimensions (receiver): 44 x 33 x 17 mm [1.732 x 1.299 x 0.669“]
Range: max. 30 meters [32.808 yd] (unobstructed area)
200 meters [218.72 yd] with antenna
Wireless hand-held transmitter
Number of operations: 2 channel
Power supply: Lithium CR 2016.31 battery
Service life of batteries: 18 - 24 months
7. Technical specifications
