Winkhaus STV
Operating Manual EAV 0124653 0505
Subject to technical changes
Winkhaus STV GmbH & Co. KG · Berkeser Str. 6 · D-98617 Meiningen · Germany · www.winkhaus.de · stv@winkhaus.de
• The manufacturer shall not be held liable for damage caused by use contrary to the
intended purpose of the product.
• For security reasons, the lock has been designed to be used in conjunction with
genuine Winkhaus parts. Using other parts may adversely affect the given properties
of the security lock.
• It must be ensured that the door can be closed without any problems by the key.
• Installation/Repair of electrical equipment requires expertise, thus such work should
only be carried out by an electrician.
• Arbitrary modifications, changes or makeshift repairs are not permitted due to
concerns for safety. You must only use genuine Winkhaus parts for replacements.
• The manufacturer shall only be held liable for security related properties of the
locking system as stipulated within the bounds of statutory regulations, if the
manufacturer himself or another instructed, authorized agent has carried out the
maintenance and service work or made the changes.
• Winkhaus STV shall not be liable for any type of damage caused by inadequate
repair or changes made.
1.6. Abbreviations/Explanations
The following terms and abbreviations are used in this manual:
STV Security lock
AV2 Automatic locking system
EAV Electronic automatic locking
system
Handle Door handle
Grt. Set
SB FRA Center strike – latch/bolt/
leveling member
M2 with 2 massive hooks
RS DIN-right-handed
LS DIN-left-handed
mc Surface mat chrome-plated
est stainless steel
gr gray pulverized
Reader Reader unit/control unit of the
transponder set
AC Alternating current
DC Direct current
NO Make contact
NC Break contact
NO-NC Changer contact
ANT/GND Auxiliary antenna/Ground
UP-socket Flush-type box
LED Light emitting diode
1. Important information
