Page 36
Winkhaus STV
Operating Manual EAV 0124653 0505
Subject to technical changes
Winkhaus STV GmbH & Co. KG · Berkeser Str. 6 · D-98617 Meiningen · Germany · www.winkhaus.de · stv@winkhaus.de
Power consumption: 13 mA
Frequency: 433.92 MHz
Number of code combinations: 2 to the power of 64 (as “Rolling Code“)
Modulation: AM/ASK
Rated output E.R.P.: 50 - 100 µW
Range in an unobstructed area: max. 30 m [32.808 yd]
Dimensions
(wireless hand-held transmitter): 61 x 36 x 16 mm [2.402 x 1.417 x 0.630“]
Wireless receiver (separate)
Receiver type: Superheterodyne
Modulation: AM/ASK
Frequency: 433.92 MHz
Frequency of the local oscillator: 6.6128 MHz
Intermediate frequency: 10.7 MHz
Sensitivity (to receive signals): 115 dB
Input impedance: 50 Ohm
Maximum memory capacity: 85 codes for hand-held transmitter
Power supply: 12/24 V AC/DC
Closed-circuit current: 15 mA
On-load current: 33/48 mA
Number of relays: (1 NO-NC)
Power: 24 W
Dimensions: 80 x 80 x 50 mm [3.150 x 3.150 x 1.969“]
7.3. Cable transition
Cable transition KÜ-T STV
Measurements: total component length of about 222 mm [8.740“]
Number of wires: 5
Cross section of wires: 0.25 mm²
Sash element: with a cable of 2 m [2.187 yd]
Frame element: with a cable of 4 m [4.374 yd]
Max. voltage: 24 V DC
Max. switching current: 2 A per connection line
7. Technical specifications
