4 Operation/Programming
4.1. Electronic automatic locking system
4.1.1. Locking and unlocking
Locking:
• Even when closing the door it is automatically locked by two massive hooks and the
latch in the main locking house.
• Additional protection is provided by manual locking: one rotation of the key
(1 x 360°) causes the dead bolt in the main locking house to be moved out.
Opening the door from outside:
• Unlocking via the connected access control system (e.g. transponder, wireless remo-
te control) or with a key.
NOTICE!
The main dead bolt for additional protection must be unlocked by keys in
any case.
Opening the door from inside, e.g. via:
• the button
• the intercom (floating contact button!)
• the handle or key*
* even possible in case of power failure
4.2. Electronic automatic door locking system with transponder
4.2.1. Operation
The reader unit controls and monitors the access to the door.
• It is operated by means of transponders that work contactless.
• Hold a tutored transponder chip into the proximity (0 - 8 cm, [0 - 3.150“]) of the
antenna.
• Once the transponder chip is close enough to where it can read the information,
communication is established contactfree.
• The transponder data are transmitted to the reader unit via the antenna.
• An acoustic signal at the reader unit will acknowledge the data transfer.
• The reader checks whether this transponder chip is authorized to access and okays
or denies access.
