Page 9
Winkhaus STV
Operating Manual EAV 0124653 0505
Subject to technical changes
Winkhaus STV GmbH & Co. KG · Berkeser Str. 6 · D-98617 Meiningen · Germany · www.winkhaus.de · stv@winkhaus.de
No. Name
Included
in
standard
delivery
of the
security
lock
MUST!
be
used*
Available
as
accessory
or as an
option
Supplied by
customer/
not included
in standard
delivery
[1] Automatic locking AV2
(AV2-F/U ...)
X X
[2] Motor box X X
[3] Extension keep set/single strike X X
[4] Center strike FRA ... X X
[5]
[5.1]
[5.2]
Cable transition (KÜ-T STV)
Cable at the sash side 2 m
[2.187 yd] or 2.5 m [2.734
yd] long, plug for motor box
included
Cable at the frame side 4 m
[4.374 yd] long
X X
[6] Power supply 12 V DC/1 A X
[7] Access control system (shown:
antenna of the transponder set)
NOTICE! Only install the
antenna of the transponder
set in the external zone
around the entry door!
X
[8] “Open” key X
[9] Flush-type box X
[10] Handle X
* remaining components recommended for use, or should be used alternatively
2. Product description
