Winsol So! - Lighting & Audio Troubleshooting; Louvre & Sensor Troubleshooting

Pergola SO! | User manual
NO
YES
2.2.1 Lighting turned on?
YES
See video: controlling lighting
NO
2.2.2 Connect the lighting to 12/24V.
OK?
YES Replace the Casambi receiver
NO
2.2.3 Replace the lighting
2.3 Check the transformer. 12/24V output?
YES
Replace the transformers
YES
2.4 Replace the Casambi module OK?
YES
NO Go back to 2.2
3 Audio does not work
3.1 Power supply OK?
YES
Power supplied
YES
3.2 Bluetooth on? YES Turn on Bluetooth
YES
3.3 Restart App or turn airplane mode on
and off OK?
YES
NO
3.4 ‘Winsol’ visible in list with Bluetooth de-
vices?
YES Device is not compatible
NO Somebody is already connected.
3.5 Turn the power off and on. Audio signal? YES Device is not compatible
NO
3.6 Check speakers connection OK?
YES
Arrange the connection
YES
3.7 Check the antennae connection OK? YES Arrange the connection
YES
3.8 Check the transformer 24V output?
YES
Replace the transformers
YES
Replace the audio module and/or the
speakers
4 Louvres do not work
4.1 Connected to the network? YES Refer to 1
YES
4.2 Line below round logo?
Yes
YES
4.2.1 Turn off all sensors Louvres react? YES Check settings + hardware sensors
Yes
4.2.2
- Connect brown and blue wires of
motor to 24V
- Swap brown and blue around
Engine reacts?
YES Replace the motor
YES
4.2.3 Test module with new motor OK?
YES Replace the motor
YES
Replace the louvres module
4.3 Check the transformer 24V output? YES Replace the transformers
YES
4.4 Replace the Casambi module OK?
YES
NO Go back to 4.2
5 Sensors do not work
5.1 Connected to the network?
YES
Refer to 1
YES
5.2 Four dots below the round logo?
Rev. 16:24 18/03/2023
Page 16/27
