23INSTRUCTION MANUAL AIR HEATER TYPE TR
Display Error type Description Case #
E-21 and 22 Heat exchanger
sensor error
Heat exchanger sensor not
detected
4
E-27 and 28 Heat exchanger
sensor error
Heat exchanger sensor
short-circuit
4
E-34 Reset button
error
Too many reset actions in a
short timespan
9
E-36 Overheating Heat exchange sensor is
overheated
3
E-38 and 39 Heat exchanger
sensor error
Heat exchanger sensor not
detected
4
E-47 and 48 Heat exchanger
sensor error
Heat exchange sensor
short-circuit
4
E-49 to 64 Internal error Internal error 13
E-65 Voltage too low Supply voltage is too low
for over 1 minute
E-66 Voltage too high Supply voltage is too high
for over 1 minute
E-67 Pressure switch
error
Too many pressure switch
errors
11
E-69 Configuration
error
Heater configuration error 19
9.3 Warnings
The table below describes the temporary warnings that
can occur. The heater may still be working, or stops until
the cause has been resolved.
Display Error type Description Case #
A-02 Configuration
error
Heater configuration error 19
A-07 Overheating Heat exchange sensor is
almost overheated
3
9.4 Instructions
After identifying the problem, use the Case number to find
the possible cause in this paragraph.
Case 1: Flame lasts only 5 seconds after ignition.
• The flame is not detected:
– Check the ignition/ionisation cable and the
electrode. The cable should have a resistance
of 1 kΩ.
• The air heater is not earthed properly.
• The circuit board is defective.
Case 2: No flame after ignition.
• There is not enough gas pressure.
• The gas mixture is too poor:
– Adjust the gas valve (see §8.1).
• The gas valve does not open:
– During ignition, check for a 230 V voltage on
the valve.
• Check if the ignition electrode sparks. If not:
– Check the cable and electrode and replace
them when damaged.
– Check the burner control unit and replace it
when it does not give a spark output.
Case 3: Heat exchange sensor or flue sensor is overheated.
• Check if the connectors J12 and J6 are plugged in
correctly and if the connection J12[1-4] (optional
overheating protection) is closed.
• Check if the system fan supplies enough air.
• Check the settings of the gas valve. The heater may
be overfired. If so:
– Adjust the burner pressure.
Case 4: Heat exchange sensor or flue sensor not detected,
or short circuit.
NOTICE L-25 refers to the heat exchange sensor. L-26
refers to the flue sensor, if applicable.
• The heat exchange sensor consists of two internal
sensors. The readings of these sensors may dier
too much:
– Measure the resistance of each sensor. The
resistance should be 20 KΩ at 25 °C and 25
KΩ at 20 °C.
– If the measured values dier too much,
replace the sensor.
Case 5: Too many flame failures while burning.
• The gas supply is not constant. This results in a
drop in gas supply pressure while burning and
causes the flame to extinguish.
– Check the gas supply pressure while the
heater is burning.
• The burner pressure for Low fire is too low. This
causes the flame to extinguish because it is too
small to be detected.
– Check the burner pressure at Low fire and
adjust if necessary (see §8.1).
• Recirculation of flue gas. Due to a problem with the
flue terminal the flue gas is sucked back into the air
inlet. This results into a lack of oxygen and causes
the flame to stop.
– Check the flue system and fresh air supply.
Only certified, original parts should be used.
Case 9: Too many reset actions in a short timespan.
• This error will disappear after some time or if the
main power is disconnected for a while.
Case 11: Insucient air passage through the heat
exchanger. Pressure switch does not close.
