7INSTRUCTION MANUAL AIR HEATER TYPE TR
3.2 Gas types
3.2.1 Natural gas G20
Specification Unit Natural gas G20
Nominal supply pressure mbar 20
Supply pressure (min. - max.) mbar 17-25
Gas category - II
2
H
3
P B/P
NL: II
2
EK
3
B/P
DE: II
2
ELL
3
B/P
BE: I
2
E(s), I
2
Er
FR: II
2
Er
3
B/P
PL: II
2
ELwLs
3
B/P
Class - B23, C13, C33
Specification Unit TR10 TR15 TR20 TR24 TR28 TR40
Gas consumption (max.) m
3
/h 1.1 1.7 2.1 2.5 3.1 4.4
Burner injectors n x Ømm 2x 1.9 3x 1.9 4x 1.9 5x 1.9 6x 1.9 8x 1.9
Burner pressure high mbar 15.0 14.5 13.0 12.0 13.0 16.0
Burner pressure low mbar 10.5 11.5 7.0 8.5 9.0 11.0
CO
2
High (indication) % 8.0 8.2 8.0 8.0 8.0 9.0
Specification Unit TR50 TR60 TR80 TR100 TR125 TR150
Gas consumption (max.) m
3
/h 5.4 6.9 8.6 11.2 14.0 16.1
Burner injectors n x Ømm 10x 1.9 5x 3.2 6x 3.7 8x 3.7 9x 3.7
1x 3.5
11x 3.7
1x 3.5
Burner pressure high mbar 15.0 11.8 7.0 7.3 6.3 6.0
Burner pressure low mbar 9.5 5.8 3.3 3.4 3.1 3.1
CO
2
High (indication) % 8.5 8.5 8.7 8.6 8.5 8.2
