8
3.2.2 Propane
Specification Unit Propane G31 (P)
Nominal supply pressure mbar 30-50
Supply pressure (min. - max.) mbar 25-50
Gas category - II
2
H
3
P B/P
NL: II
2
EK
3
B/P
DE: II
2
ELL
3
B/P
BE: I
3
P
FR: II
2
Er
3
P
PL: II
2
ELwLs
3
B/P
Class - B23, C13, C33
Specification Unit TR10 TR15 TR20 TR24 TR28 TR40
Gas consumption (max.) kg/h 0.9 1.2 1.6 1.9 2.4 3.3
Burner injectors n x Ømm 2x 1.4 3x 1.4 4x 1.4 5x 1.4 6x 1.3 8x 1.4
Burner pressure high mbar 23.0 21.3 18.5 16.5 22.5 20.5
Burner pressure low mbar 16.0 17.0 10.0 12.3 15.5 14.5
CO
2
High (indication) % 9.0 9.3 9.0 8.8 9.5 9.5
Specification Unit TR50 TR60 TR80 TR100 TR125 TR150
Gas consumption (max.) m
3
/h 4.1 5.2 6.4 8.4 10.5 12.1
Burner injectors n x Ømm 10x 1.4 5x 2.3 6x 2.3 8x 2.3 10x 2.3 12x 2.3
Burner pressure high mbar 20.3 19.0 19.0 17.7 19.3 17.4
Burner pressure low mbar 12.4 9.4 9.0 8.5 9.5 8.9
CO
2
High (indication) % 9.7 10.0 9.5 9.5 9.5 9.5
3.2.3 Butane
Specification Unit Butane G30 (B/P)
Nominal supply pressure mbar 30-50
Supply pressure (min. - max.) mbar 25-50
Gas category - II
2
H
3
P B/P
NL: II
2
EK
3
B/P
DE: II
2
ELL
3
B/P
BE: I
3
B/P
FR: II
2
Er
3
B/P
PL: II
2
ELwLs
3
B/P
Class - B23, C13, C33
Specification Unit TR10 TR15 TR20 TR24 TR28 TR40
Gas consumption (max.) m
3
/h 0.7 0.9 1.2 1.4 1.7 2.5
Burner injectors n x Ømm 2x 1.4 3x 1.4 4x 1.4 5x 1.4 6x 1.3 8x 1.4
Burner pressure high mbar 18.0 16.5 14.0 13.0 17.5 16.0
Burner pressure low mbar 13.0 13.0 8.0 9.5 12.0 11.5
CO
2
High (indication) % 9.2 9.2 9.2 9.2 9.2 9.2
Specification Unit TR50 TR60 TR80 TR100 TR125 TR150
Gas consumption (max.) kg/h 3.1 3.9 4.9 6.4 7.9 9.1
Burner injectors n x Ømm 10x 1.4 5x 2.3
14.5
6x 2.3
14.3
8x 2.3
13.8
10x 2.3
14.9
12x 2.3
13.3
Burner pressure high mbar 16.0 7.4 6.0 6.5 7.5 7.1
Burner pressure low mbar 9.3 9.2 9.2 9.2 9.5 9.5
CO
2
High (indication) % 9.2 4.9 6.4 6.4 7.9 9.1
