Wintriss Shadow VI - Figure 2-5. Top Views of Shadow VI Optic Heads (Universal Mounts)

1107200 Shadow VI User Manual
page 32 Chapter 2 Installation and Checkout
3.25
(82,6)
30°
1.5
(38,1)
30
°
1.5
(38,1)
2.55
(64,8)
1.05
(26,7)
2.10 (53,3)
2.75 (69,9)
Dimensions:
inches
(mm)
Figure 2-5. Top Views of Shadow VI Optic Heads (Universal Mounts)
