External MPCE Monitoring: Checking DS5 and DS6
These LEDs help diagnose problems relating to external MPCE monitoring. If you are using
external MPCE monitoring do the following:
1. Block the light curtain and look at LEDs DS5 and DS6 (see Figure 2-14 for location).
They should both light up orange.
2. If only one lights up, or if neither lights up, check the machine control circuit.
3. Verify that MPCE wiring is correct and check that MPCE jumpers J14 and J15 are both
set for “external.” See Chapter 2.
Table 4-2. Shadow Troubleshooting Guide for 2 Sets
Control
Set
#
Description
Transmitte
r
Receiver
Indicators
DS1 & 2
Action
.
Chapter ref.
#1
#2
Set #1 optic heads
are blocked.
Amb
Amb
Red
Grn
Red
1 Red
2 Off
3 Grn
4 Grn
7 Off
8 Grn
1. Make sure a part of the machinery or
other object is not inadvertently
protruding into the light field.
2. Check lens cover(s) for dirt buildup
-
4
#1
#2
Set #2 optic heads
are blocked.
Amb
Amb
Grn
Red
Red
1 Off
2 Red
3 Grn
4 Grn
7 Off
8 Grn
and clean if necessary.
3. Check alignment. Realign if necessary. 2
#1
#2
Sets #1 and #2
optic heads are
both blocked.
OR
Transmitter #1 is
wired with
receiver #2 and
vice versa.
Amb
Amb
Red
Red
Red
1 Red
2 Red
3 Grn
4 Grn
7 Off
8 Grn
1. Complete steps 1, 2 and 3, above.
2. If this does not solve the problem, check
to see if transmitter and receiver
connections are reversed. If you cannot
trace the problem, go to the section that
immediately follows this table for
further instructions.
4, 2
2
#1
#2
Relays are
chattering on
and off.
Amb
Amb
Grn
Grn
Flicker
betw/
Grn &
Red
1 Off
2 Off
3 Grn
4 Grn
7 Off
8 Grn
1. Optic head jumper setting is incorrect (1
set vs. 2 sets). Check that both
“1 set/2 sets” jumpers at J12 are set at
“2 sets.”
2
