Upgrading from Original SmartPAC or SmartPAC 2 to SmartPAC PRO 1145200
Instruction Sheet 7
Original SmartPAC
SmartPAC PRO RTS
Signal Type
Connector
Pin
number
Connector
Pin number
AutoSetPAC / WaveFormPAC 2 or 4 Channel (Optional)
GRD.
TB102
240
TB6
240
+RXD2
TB102
241
TB6
241
-RXD2
TB102
242
TB6
242
+TXD2
TB102
243
TB6
243
-TXD2
TB102
244
TB6
244
SFI (Optional)
+RXD1
TB102
235
TB6
235
-RXD1
TB102
236
TB6
236
TXD1
TB102
237
TB6
237
+TXD1
TB102
238
TB6
238
-TXD1
TB102
239
TB6
239
GRD.
TB102
240
TB6
240
MultiPAC (Special Port - Optional)
+RXD3
TB103
224
TB7
224
-RXD3
TB103
225
TB7
225
TDX3
TB103
226
TB7
226
+TXD3
TB103
227
TB7
227
-TXD3
TB103
228
TB7
228
GRD.
TB103
229
TB7
229
