Operating Manual V-Drive
+
/V-Drive economy
Page en-16
Index: 11 2022 D005924 Release: 30.04.2019
6.4 Putting into operation
Please observe the instructions in the „General Safety Instructions” in section
3.3.1.
When using the gearbox in continuous duty operation (S1
operation), we recommend the use of a ventilation screw.
The ventilation screw is not included in the scope of delivery.
WITTENSTEIN alpha GmbH offers suitable ventilation screws to
this end (see Table 6.8). If you would like to order a ventilation
screw, contact our sales department.
Ventilation screw
V-Drive gearbox size 040 050 063 080 100
Material number for
ventilation screw
20070677 20071468
(only with ordering code
xxx040x-xxx-xxx-xxx-xx-XDx)
20070677
Thread size G1/4" G3/8" G1/4"
Table 6.8
6.5 Changing the torsional flank backlash (optional)
For special applications, there is the option of changing the torsional flank backlash.
The procedure for setting the torsional flank backlash can be found in the
appendix: section 11.2.
7 Operation
7.1 Operating conditions
Please observe the instructions in the „General Safety Instructions” in section
3.3.1.
The gearbox must be installed in a clean and dry environment. Coarse dust and liquids of all
kinds impair its function.
The specifications for lubricants and operating temperatures can be found in section 4.3.
Avoid icing, which can damage the seals.
Divergent operating conditions may make different lubricant quantities and different
lubricants necessary.
In these cases, please consult our Customer Service Department (see 1.1).
DANGER!
Excessive loads or impacts can cause the output flange/output shaft to tear off.
Falling loads or breakage of machine parts can cause injury.
Comply with the maximum permitted forces and torques.
Do not stand under suspended loads.
