WLKATA Mirobot Manipulator User Manual
Document version 1.0 User Manual Copyright© Beijing Tsinew Technologies Co., Ltd.
The shape design of the Bluetooth teach pendant combined with ergonomics allows users
to easily control and operate with both hands.
Product Name
Mirobot Teach Pendant
Product Size
Long：145±2mm Width：113±2mm Height：31±2mm
Weight
170g
Power
1000mAh
Voltage
3.7V
Operating Temperature
-10°C~45°C
Appearance of Mirobot teach pendant
3.6.2.2 Teach pendant control page composition and main function description
The Mirobot teach pendant is mainly composed of angle mode, coord. mode, record and
setting function pages.
（1）Angle Mode page
The angle mode page is mainly responsible for the motion control of each axis of the
manipulator.
