WMF 1120 Series User Manual

108
User Manual WMF1100 S
Appendix: Technical data
Appendix: Technical data
Technical data for coffee machine
External dimensions Width 325mm
Depth 561mm
Housing height 460mm
Height including display 500mm
Height including hopper extension 556mm
Bean hopper Approx. 550g; with optional extension approx. 1,100g
(1
Powder hopper Approx. 450g; with extension approx. 1,250g
(2
Weight empty 24–28kg (depending on the model)
Water supply 3/8inch hose connector with water mains tap, and filter
with 0.08mm mesh size, on-site.
(3
At least 0.2MPa (2bar) supply pressure at 2l/min
Maximum 0.6MPa (6bar).
Maximum inlet temperature 35°C.
The set of hoses provided with the new coffee machine
and/or the new water filter must be used. Do not use the
old set of hoses.
Water quality For drinking water with carbonate hardness from 5°dKH
or higher, aWMFwater filter must be fitted.
Water drain tube
(optional)
Hose aminimum of DN 19, minimum downward slope of
2cm/m
Water tank volumes approx. 4.5l
Use at elevation above
sea level
< 2,000m
We reserve the right to make technical modifications.
(1
The capacity depends on the size of the coffee beans.
(2
Only with optional powder hopper. The capacity depends on the powder used.
(3
These specifications (IEC60335–2-75) for the water connection to the coffee
machine apply in EU member states. It may be necessary to also observe
additional country-specific regulations. Outside the EU acceptance of the
standards quoted is to be checked by the legal entity or natural person who
wishes to use the coffee machine.
