Induction Cooktop
Installation Information
2-6
Counter top Cut-out Dimensions (CT36I )
The CT36I is designed to fi t a 39” (838mm) minimum
width base cabinet with a 25” (635mm) deep counter
top. Before making the counter top cut-out, verify that the
cooktop will clear the side walls of the base cabinet below.
A Wolf 30” (762mm) or 36” (914mm) built-in single oven
may be installed below Model CT36I. For this installation,
unless the cabinets are deeper than 24” (610mm), it is
recommended that the electrical supply be placed in the
base cabinet to the right of the oven. Refer to installation
instructions provided with the built-in oven for additional
specifi cations. (See Figure 2-7 & 2-8)
NOTE: Locate the junction box within reach of the 48”
(1219 mm) conduit, and accessible when the cooktop unit
is installed.
2"*min (51)
18"
(457)
(64)
13" max
(330)
30" (762)
24"min
(610)
3
3
/4"min
2"**
(51)
10"
(254)
3
1
/2" (89)
E
39" (991)
RECOMMENDED
CABINET WIDTH
36" min (914)
COUNTERTOP TO
COMBUSTIBLE
MATERIALS
ABOVE COOKTOP
CUT-OUT TO
COMBUSTIBLE
MATERIALS
BOTH SIDES
19-1/4”(489)
COOKTOP
CUT-OUT
DEPTH
2-1/2” min
36" (914)
FLOOR TO
HEIGHT
STANDARD
COUNTER
36” OVEN OPENING
34-3/8” (873) COOKTOP
CUT-OUT WIDTH
4-1/2”(114)
(95)
(64)
WIDTH
COOKTOP CUT-OUT
COOKTOP
DEPTH
CUT-OUT
19-1/4” (489)
2-1/2” MIN
FRONT OF COUNTERTOP
34-3/8” (873)
Figure 2-7 CT36I Counter top Cut-Out Top View
Figure 2-8 CT36I Counter top Cut-Out
NOTE: *Minimum clearance from both side edges of cooktop cut-out to combustible materials up to 18” (457mm)
above counter top. **Minimum clearance from rear edge of cooktop cut-out to combustible materials up to 18” (457mm)
above counter top.
NOTE: Unit dimensions may vary to ±1/8” (3mm).
