Induction Cooktop
Electronic Control
3-11
Showroom Mode
This mode deactivates the induction coils while still giving
the user complete functionality of the controls at either
120V or 240V power.
To activate Showroom Mode
From LOCK MODE, Press and hold the front element
“MELT” keypad for 5 seconds. The controls will enter
showroom mode. (See Figure 3-17)
NOTE: If any other key pad sensor detects another input
signal, the Showroom Mode will not engage.
NOTE: If the “MELT” key pad is not released after 7
seconds, the Showroom Mode will be cancelled and not
engaged. The unit will return to Lock Mode.
The controls will light all LEDs for 5 seconds to let the
user know that showroom mode has been entered.
During showroom mode “Shr” will be continually
displayed in the timer display unless the “CLEAR”, ‘+” or
“-” key is pressed. Once there are no key presses for 5
minutes the “Shr” will return.
While in Showroom Mode, all inductors will be disabled
and all visual and audible feedback will function as
normal.
To exit Showroom Mode
From LOCK MODE, Press and hold the front element
“MELT” keypad for 5 seconds. The controls will exit the
showroom mode. (See Figure 3-17)
The Controls will go through the start up sequence to
indicate that the showroom mode has been exited.
NOTE: An interruption of power will also exit the
showroom mode and the unit will start up in LOCK mode
when power is restored.
NOTE: If any other key pad sensor detects another
input signal, the Showroom Mode will not dis-engage.
NOTE: If the “MELT” key pad is not released after 7
seconds, the Showroom Mode will not be cancelled. The
unit will return to Lock Mode in the Showroom Mode.
MELT
OFF ON
CLEAR
OFF
HIGH
OFF ON HIGH
Shr
SIM
H
I
P
O
W
E
R
Touch and
Hold “Melt” Key
for 5 Sec.
Figure 3-17 Entering or Exiting Showroom Mode
MELT
OFF ON
CLEAR
OFF
HIGH
OFF ON HIGH
000
SIM
H
I
P
O
W
E
R
Touch and
Hold “OFF” Key
for 5 Sec.
Figure 3-18 Entering Diagnostics Mode
