38 .50 Series Parts
MAN1246 (04/10/2018)
BW10.50E / BW10.50QE WEIGHT BOX ASSEMBLY
REF PART QTY DESCRIPTION
1 11900 10 Nut lock 1/2 NC flange
2 23479 10 HHCS 1/2 NC x 5 GR5 ZP
3 57123 1 Dcl 2 x 9 rear reflector
4 1033958 2 Screw .375 NC x 1 - .25 HEX FLNG SER
5 1041910 1 Decal, notice, light kit
6 1045084 1 Plate, WT box skid
7 1045088 1 WA, WT box hinge
8 1045090 5 Plate, WT box inner
9 1045091 1 Plate, WT box outer
10 1045095 1 WA, WT box mount
11 1045628 2 Nut, HFN 3/8 NC, dri-loc patch
12 1045883 1 Lug, WT box reflector
13 1046095 1 Plate, WT box inner notch
HHCS Hex head cap screw
