Manual 02879 723PLUS/Analog Load Sharing
Woodward 81
3. FUEL DEMAND displays the percent fuel demand. This is NOT the same
as the actuator output if configured for reverse acting. This is the same if
configured for direct acting.
4. SPEED REF displays the output of the speed reference ramp before any
biases are applied.
5. LOAD BIAS displays the value, in rpm, that the load control is biasing the
speed reference.
6. DROOP BIAS displays the value, in rpm, that the droop percentage
calculation is biasing the speed reference.
7. SYNC BIAS displays the value, in rpm, that the synchronizer input is biasing
the speed reference.
8. REMOTE SPEED REF displays the present remote speed reference signal
in rpm.
9. EXT FUEL LIMIT IN displays the present external fuel limit input value in
engineering units.
10. EXT FUEL LIMIT displays the present percent fuel demand limit of the
external fuel limiter.
11. FD REPRESENTATION (kW) displays the present generator kW based on
the fuel demand. This display value is established by the KW SETTING
menu entries FUEL DEMAND @ MIN LD (%FD) for the 0 kW value, FUEL
DEMAND @ MAX LD (%FD) and RATED LOAD (kW) for the rated load
value. Intermediate %FD values will produce intermediate kW values.
12. REM LD SETPT (kW) displays the present remote load reference signal in
kW.
13. BASE LOAD REF (kW) displays the present base load reference ramp
output in kW.
14. LOAD REFERENCE (kW) displays the present load reference ramp output
in kW.
15. GENERATOR OUT (kW) displays the present generator kW based on the
kW transducer input. This display value is established by the SET ANALOG
INPUTS menu entries KW SENSOR @ 4 mA (kW) and KW SENSOR @ 20
mA (kW). Intermediate mA values will produce intermediate kW values.
