Manual 37427 easYgen-2000 Series - Genset Control
© Woodward Page 261/339
Configure Interfaces: Configure RS-232 Interfaces
Configure Serial Interface 1
Parameter table
Level
Text
Setting range
Default value
Configure RS-232 interfaces: serial interface 1
Baudrate
2.4 / 4.8 / 9.6 / 14.4 / 19.2
38.4 / 56 / 115 kBd
19.2 kBd
Parity
No / Even / Odd
No
Stop bits
One / Two
One
ModBus Slave ID
0 to 255
1
Reply delay time
0.00 to 1.00 s
0.00 s
Table 3-114: Application - standard values - configure RS-232 interface: serial interface 1
EN Baudrate Serial interface 1: Baud rate 2.4 / 4.8 / 9.6 / 14.4 / 19.2 / 38.4 / 56 / 115 kBaud
This parameter defines the baud rate for communications. Please note, that all
participants on the bus must use the same baud rate.
DE Baudrate
CL2
3163
{0}
{1o}
{1oc}
{2oc}




EN Parity
Serial interface 1: Parity no / even / odd
The used parity of the interface is set here.
DE Parity
CL2
3161
{0}
{1o}
{1oc}
{2oc}




EN
Stop bits
Serial interface 1: Stop bits one / two
The number of stop bits is set here.
DE Stop Bits
CL2
3162
{0}
{1o}
{1oc}
{2oc}




EN ModBus Slave ID Serial interface 1: Modbus Slave ID 0 to 255
The Modbus device address, which is used to identify the device via Modbus, is
entered here. If "0" is configured here, the Modbus is disabled.
DE
ModBus Slave ID
CL2
3185
{0} {1o} {1oc} {2oc}




EN Reply delay time
Serial interface 1: Reply delay time 0.00 to 1.00 s
This is the minimum delay time between a request from the Modbus master and the
sent response of the slave. This time is also required if an external interface
converter to RS-485 is used for example.
DE
Zeitverzöger. der Antwort
CL2
3186
{0}
{1o}
{1oc}
{2oc}




