The Digistat Optimising Programmer
This is a 5-2 Day / 7 Day programmable thermo-
stat product. 5–2 day allows you to set a program
for weekdays and a program for the weekend.
Full 7-day functionality allows you to set a different
program for every day of the week.
Each program type allows you to set 6 time and
temperature events.
Pre-set Program 1
The following default settings are pre-programmed
for your convenience:
Monday - Friday
Event 1 2 3 4 5 6
Time 06:30 08:30 12:00 14:00 16:30 22:30
Temp. 20 16 16 16 21 7
As shown, at 06:30 , the heating will come on to
raise the temperature to 20°C. At 08:30, the
temperature set point is dropped from 20°C down
to16°C, it stays at 16°C throughout the day, until
16:30 when the temperature increases to 21°C.
The temperature then drops down to a night-set-
back temperature of 7°C until 06:30 when the
cycle repeats for the next day. (Monday to Friday)
For changes to weekend setting see below.
Saturday - Sunday
As shown, at 07:00, the heating will come on to
raise the temperature to 20°C. At 09:00, the
temperature set point is dropped from 20°C down
to18°C, it stays at 18°C until 12:00 when the
heating comes on to raise the temperature to
21°C. The temperature stays at 21°C until 14:00
when it drops down to 18°C.
At 16:30 the heating comes on to raise the
temperature to 21°C where it stays until 23:00
when the temperature then drops down to a night-
setback temperature of 7°C until 07:00 when the
cycle repeats for the next day. (Saturday and
Sunday) or changes to weekday settings see
above.
DIGISTAT OPTIMISER
PRE-PROGRAMMED SETTINGS
Event 1 2 3 4 5 6
Time 7:00 9:00 12:00 14:00 16:00 23:30
Temp. 20 18 21 18 21 7
DT10RF OPTIMISING PROGRAMMER
INSTRUCTION MANUAL
8 716 115 494a (02.2009)
OPERATING & INSTALLATION
INSTRUCTIONS
5
