35
Option 5
Plume management system with extensions and 45º bends
Maximum
Components required
length (mm)
Greenstar Ri series
60mm 3,000 1 up to 3 2
Greenstar CDi Classic Regular series
60mm 3,000* 1 up to 3 2
*NOTE: You must refer to the table and graph on page
33 to calculate your horizontal flue lengths and plume
management length.
