Worcester Greenstar i Series User Manual

APPLIANCE INFORMATION
6 720 804 532 (2012/09) 5
2 APPLIANCE INFORMATION
2.1 APPLIANCE
2
4
3
5
* 710mm to top of case front
1
700mm*
400mm
330mm
Depth to wall
(When fitted to wall frame)
6
6720644743-01.3Wo
STANDARD PACKAGE:
1 Wall hung gas fired condensing system boiler for central
heating and hot water
2 Wall mounting frame
3 Hardware literature pack (see checklist)
4 Bottom Panel
5Fascia panel
6Syphon assembly

Worcester Greenstar i Series Specifications

General

Model	Greenstar i Series
Mounting	Wall-mounted
Maximum Working Pressure	3 bar
Fuel Type	Natural Gas
Dimensions	400mm (W)
Warranty	Up to 10 years
Efficiency	Up to 94%
Heating Flow Temperature Range	30°C to 80°C
Output Rating	35kW
