2. Mount the dust extraction adapter
7
on the connecting nozzle
4
(see fig.Aand D).
3. Connect a suitable suction device to the dust extraction adapter
(e.g. shop vacuum cleaner).
Mounting tools
CAUTION!
Risk of injury!
If you mount the tools incorrectly and they are therefore able to
come into contact with your hand during use, there is a risk of injury.
− Do not mount the tools such that there is a possibility of them
coming into contact with your hand. For example: Ensure that
the blades are not pointing towards your hand.
Depending on the application, mount the tools listed below:
Plunge-cut saw blade
Example of use: Sawing slots (see fig. G).
1. Place the plunge-cut saw blade
15
on the tool holder
16
at any angle
(see fig. K and fig. L).
2. Place the washer
10
on the plunge-cut saw blade with the concave side up.
3. Use the Allen wrench
8
to tighten the Allen head screw
9
.
Scraper
Example of use: Removing coatings, lacquer coats or floor surfaces (see fig. H).
1. Place the scraper
14
on the tool holder at any angle (see fig. K and fig. L).
2. Place the washer on the top of the scraper with the concave side up.
3. Use the Allen wrench to tighten the Allen head screw.
Segment saw blade
Example of use: Flush cutting fitted door frames to length (see fig. I).
1. Place the segment saw blade
13
on the tool holder at any angle
(see fig. K and fig. L).
2. Place the washer on the top of the segment saw blade with the concave side up.
3. Use the Allen wrench to tighten the Allen head screw.
Sanding plate
Example of use: Grinding surfaces in inaccessible corners (see fig. J).
1. Place the sanding plate
11
on the tool holder at any angle (see fig. K and fig. L).
