15
Compact circular saw WX427
the tooth count of the saw blade. Therefore,
use only sharp saw blades that are suited for
the material being cut.
Choice of blades: 24 teeth for general work,
approx. 40 teeth for finer cuts, more than 40
teeth for very fine cuts into delicate surfaces,
diamond for tile, cement board, etc.
1. MAKING CROSS CUTS AND RIP CUTS
WARNING: To avoid sudden kick-back,
never start with the stationary blade in
contact with the work.
Always start the saw and allow it to reach full
speed before plunging into work material.
a). ALWAYS use your saw with your hands
positioned correctly.
WARNING: Always maintain proper
control of the saw to make sawing safer
and easier. Loss of control of the saw could
cause an accident resulting in possible serious
injury.
b). When making cross or rip cuts, align your
line of cut with the center of the “V” notch
located on the front of the saw’s base.
c). Since the thickness of blades varies, make
a trial cut in scrap material along the guideline
to determine how much, if any, you should
offset the blade from the guideline to allow for
the blade thickness to get an accurate cut.
MAKING RIP CUTS
Always use a guide when making long rip
cuts with your saw. You can use any suitable
straight edge clamped to the work or the
parallel guide that is included with your saw.
2. POCKET CUTTING (SOFT MATERIALS
ONLY)
This operation requires much skill with a saw
and must only be carried out by a qualified
person.
WARNING: The blade teeth are
exposed during this operation so
proceed with extreme caution.
Clearly mark the area to be cut. Set the depth
of cut on the saw. Position the saw over the
marked area with the front edge of the base
plate resting on the work surface and cutting
guide aligned with marked line on workpiece.
Ensure the blade is not touching but is close
to the work surface. The moving lower guard
must be rotated open by using lever. Switch
the saw on and gently swing the blade down
into the material but maintain a pivoting force
on the front edge of the base. The moving
lower guard can now be released for normal
action of the guard.
DO NOT bind the blade in the cut; push the
saw blade forward at a rate where the blade is
not laboring.
When the cut is complete, release the trigger
safety release and switch and let the blade
come to a complete stop. DO NOT REMOVE
the saw and blade from the workpiece while
the blade is moving. This could damage your
cut (kerf), cause kickback and loss of control,
resulting in injury.
MainTain ToolS WiTh
care
Remove the plug from the socket before
carrying out any adjustment, servicing or
maintenance.
Keep tools sharp and clean for better and
safer performance. Follow instructions for
lubricating and changing accessories. Inspect
tool cords periodically and if damaged, have
repaired by authorized service facility. Your
power tool requires no additional lubrication
or maintenance. There are no user serviceable
parts in your power tool. Never use water or
chemical cleaners to clean your power tool.
Wipe clean with a dry cloth. Always store
your power tool in a dry place. Keep the
motor ventilation slots clean. Keep all working
controls free of dust.
If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order to
avoid a hazard.
Periodically clear dust and chips from guard
and base to ensure proper performance.
