Worx WX427 User Manual

16
Compact circular saw WX427
TroubleShooTinG
Symptom Possible Causes Possible Solution
Tool will not start when
operating the on/off switch.
Power cord not plugged in.
Power cord is broken.
Carbon brush has worn
down.
Check to make sure power cord
is connected well into a working
outlet.
Unplug the power cord. Replace
it using a qualified maintenance
person.
Replace the carbon brush using a
qualified maintenance person.
Cutting depth is less than that
is set.
Sawdust accumulated at the
rear of the base.
Shake out sawdust. Consider
connecting a vacuum for dust
collection.
Blade spins or slips
Blade is not tightly engaged
with the spindle.
Remove the blade, and reassemble
it as described in INSTALL/
CHANGE THE BLADE section.
Blade will not cut a straight line.
Blade is dull.
Blade is not mounted
properly.
Saw is not being guided
properly.
Mount a new, sharp blade on the
saw.
Check that blade is properly
mounted.
Use an edge guide.
Blade kicks back when
beginning a cut
Blade is not spinning fast
enough
Allow the saw blade to reach full
speed prior to beginning a cut in the
material.

Worx WX427 Specifications

General

Product color	Black, Orange, Stainless steel
Protection class	II
Blade bore	9.5 mm
Blade diameter	120 mm
Idle speed (max)	3700 RPM
Sound power level	87 dB
Blade diameter (min)	115 mm
Cutting depth (45º)	30 mm
Cutting depth (90º)	46 mm
Sound pressure level	76 dB
Sound level uncertainty	3 dB
Saw blade included	Yes
Vibration emission	6.82 m/s²
Input power	710 W
Power source	AC

Weight and Dimensions

Weight	2300 g
