Worx WX550 Original Instructions

20V Li-Ion multi-purpose saw EN
11
Helping to minimise your vibration exposure risk.
ALWAYS use sharp blades.
Maintain this tool in accordance with these
instructions and keep well lubricated (where
appropriate).
If the tool is to be used regularly then invest in anti
vibration accessories.
Plan your work schedule to spread any high
vibration tool use across a number of days.
ACCESSORIES
WX550 WX550.1 WX550.4 WX550.9
Charger 1 (WA3860) 1 (WA3860) 1 (WA3880) /
Battery pack
(WA3551.1)
1 2 1 /
Wood cutting jig
saw blade
1 1 1 1
Metal cutting jig
saw blade
1 1 1 1
Aluminum
cutting jig saw
blade
1 1 1 1
Wood cutting rep
saw blade
1 1 1 1
bottom plate 1 1 1 1
Rough wood
and firewood
cutting rep saw
blade (WA8008)
/ / 1 /
We recommend that you purchase your accessories
from the same store that sold you the tool. Refer to
the accessory packaging for further details. Store
personnel can assist you and offer advice.
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTENDED USE
The machine is 2 saws in 1 tool with rep saw and
jig saw function, intended for sawing wood, plastic,
metal and building materials while resting firmly on
the workpiece. It is suitable for straight and curved
cuts.
ASSEMBLY AND OPERATION
ACTION FIGURE
BEFORE OPERATION
Removing the battery pack See Fig. A1
Charging the battery pack See Fig. A2, A3
Installing the battery pack See Fig. A4
Working mode adjustment
Position I worked as a jigsaw.
Position II worked as a
reciprocating saw.
NOTE: Select the blade best
suitable for the working mode
for better cutting performance
(special reciprocating saw blade
not included).
WARNING!
• To avoid being pinched,
keep hands away from the
hinge when changing positions.
• To avoid tool being turned on
accidentally, make sure keep
your hands away from the lock-
off button.
• Before operation, make sure
the pivot release button is
locked into position.
See Fig. B1-C4
ASSEMBLY
Replacing the saw blade
When using jig saw mode,
the blade teeth face outward
as shown in Fig. D1; while in
rep saw mode, the blade teeth
should face as shown in Fig. D3.
CAUTION: Keep your
hands away from the
lock-off button to prevent
switch actuation before making
any adjustments or removing
or installing attachments or
accessories.
See Fig. D1-D3
OPERATION
WARNING! Burn hazard. Do not touch the
blade immediately after use. Contact with the
blade may result in personal injury.
Switching On and Off
NOTE: For safety reasons the
On/Off switch of the machine
cannot be locked; it must
remain pressed during the
entire operation.
See Fig. E
Pendulum Function See Fig. F1, F2

Worx WX550 Specifications

General

Product color	Black, Orange
Built-in light	-
Adjustable speed	Yes
Number of blades	1
Included saw blade type	Metal saw blade
Number of batteries included	1 pc(s)
Idle stroke rate (max)	3000 spm
Idle stroke rate (min)	0 spm
Input power	- W
Power source	Battery
Charging time	60 min
Battery voltage	20 V
Battery capacity	2 Ah
Battery level indicator	No

Weight and Dimensions

Depth	165 mm
Width	257 mm
Height	127 mm
Weight	1900 g
