Users Manual | 126
APPENDIX : SPECIFICATION
MODEL
XDR4 range of H.264 DVR’s
Compression Algorithm
Video : H.264, Audio : G723.1
HDD
2ea x SATA
MAX. 4TB HDD (2TB X 2EA)
OS
Embedded Linux
Video
Input
4/8/16CH
Looping
Option: D-sub (by piggy tails)
Video Mode
NTSC / PAL Auto Detection
Display Speed (NTSC/ PAL)
4CH: 120/100 ips
8CH: 240/200 ips
16CH: 480/400 ips
Screen Split
4CH: 1,4 & PIP
8CH: 1,4,9 & PIP
16CH: 1,4,9,16 & PIP
Video-Out
Monitor
2ea x Main Monitor (Composite,VGA & HDMI),
1 x Spot Monitor (Composite)
Recording
Speed
(NTSC/PAL)
352x240/288
(CIF)
4CH: 120/100 ips
8CH: 240/200 ips
16CH: 480/400 ips
720x240/288
(2CIF)
4CH: 120/100 ips
8CH: 240/200 ips
16CH: 240/200 ips
720x480/576
(4CIF)
4CH: 120/100 ips
8CH: 120/100 ips
16CH: 120/100 ips
Recording Resolution
NTSC : 352x240, 720x240, 720x480 / PAL : 352x288, 720x288, 720x576
Recording
Modes
Recording
Profile
Two recording profiles
Event
Recording
Normal Recording Setup & Event Recording Setup Separately
Recording
Type
Continuous(C), Alarm(A), Motion(M), C+M, C+A, C+M+A
Pre-Post
Alarm
Pre & Post Alarm Recording / Pre-alarm ( 5 seconds)
Panic
Recording
Panic Recording Setup Separately (IPS, Resolution, Quality)
