XENO XDR4 range User Manual

User’s Manual | 16
2.2.12 Sensor Terminal Block
Connect sensors
2.2.13 Alarm Terminal Block
Connect various alarm devices controlled by relay output
2.2.14 Power Input
Before connecting the power cord to the system, check if the power is in accordance with the system specification.
NOTE
Support both N/O (Normal Open) and N/C (Normal Close) type of sensors. If connected sensor is not
functioning, ensure wiring is correct. The connection method may differ according to the type of P/T/Z
controller. Enquire to your vendor for guidance.

XENO XDR4 range Specifications

General

Brand	XENO
Model	XDR4 range
Category	DVR
Language	English
