User’s Manual | 12
2.1.1 DIRECTION Button
1) Live Display & Playback Mode
User can change channel number by using Left & Right arrow button.
User can change display mode by using Up & Down arrow button.
2) Menu Mode (when system menu displays)
To move to desired menu position
3) Pan & Tilt Mode (once PTZ Button is pressed)
To move connected camera to desired direction
4) Zoom & Focus Mode (when PTZ Button is pressed again)
User can control Zoom-In & Out by using Up & Down arrow button.
User can control Focus-In & Out by using Left & Right arrow button.
5) CALL Monitor Mode (once Call Monitor is pressed)
User can bring up the full screen out of spot out channels by using Up & Down arrow button.
2.1.2 ENTER Button
To select value or setting
2.1.3 EXIT Button
To exit the menu setup or return to previous mode
2.1.4 MENU Button
To set the system configuration according to user requirement
2.1.5 MODE (Press once) / FREEZE (Press and hold) Button
MODE (Press once): to select the Screen display mode
FREEZE (Press and hold): Screen display will be paused until the Freeze button is pressed again.
2.1.6 PTZ (Press Once) / I-BACK UP (Press and hold) Button
PTZ (Press once): Once pressed, DVR is changed to Pan & Tilt mode. User can control Pan & Tilt operation by using
Direction Button. If pressed again, DVR is changed to Zoom & Focus mode. User can control Zoom & Focus operation by
using Direction Button.
I-BACK UP (Press and hold): Press and hold to go to instant Back up mode.
2.1.7 INSTANT REC (Press once)
INSTANT REC (Press once): Used for emergency recording mode.
2.1.8 B-MARK (Press once) / CALL MON (Press and hold) button
Book-MARK (Press once): Used for bookmark.
