41 | Chapter 1 : DVR User Manual
In “Display Setting”, user can set sequence dwell time, spot-out dwell time, spot-out channel, pop-up camera, and OSD as
indicated below.
User can set Spot-Monitor output and sequence dwell time in this menu as well as show/hide OSD.
Transparency is the transparency level of the menu screen. 0% means no transparency at all.
You may select On/Off for Live or Playback status display by checking a check box.
How to upgrade system firmware by using USB memory stick
1) Insert the USB thumb-drive formatted by FAT32 in any USB port of DVR (compatible with USB
2.0)
2) Once the system detects the thumb-drive, user can see its brand or model name in the
“DEVICE” field after pressing the “SCAN” button.
3) Click “OK” to confirm.
How to upgrade system firmware by using FTP server
1) Select FTP in the drop-down list and type a given IP address in the Host Address (FTP server IP
address) field. Username and password is “none” (Default). *The FTP server address is subject to
change without a prior notice.
2) Click „Check‟ button then DVR will detect the latest Firmware version from the FTP server. If
there is a new firmware, DVR will ask you whether you want to upgrade it or not.
3) Click „OK‟ to confirm it and then click „START‟ to start upgrading.
It is recommended to format the HDD after finishing the firmware upgrade because the data recorded
by previous firmware may cause malfunction of DVR due to different format.
It is possible to send the system firmware back to factory default. This may be useful if functionality
takes a step backwards after a system upgrade. It is highly recommended to check all functions and
menus after a firmware upgrade for proper layout and performance.
DVRs support the following video resolutions: 800x600, 1024x768, 1280x1024, 1280x720, and more.
User must set the proper resolution according to the monitor resolution.
