XENO XDR4 range User Manual

User’s Manual | 96
7.3.2 Main Toolbar
No.
Button
Description
1
Site Manager
Register or Delete DVR on the list
2
Connect
Connect to a site that is listed on the DVR list panel
( Select Live and Search mode at Connect Mode Panel )
3
Disconnect
Disconnect a selected channel
4
Disconnect All
Disconnect All Channels
5
Print
Print out still image
6
JPG Export
Save a selected image to the desktop as JPEG format
7
Movie Export
Save a selected video clip to the desktop as mov format
8
Split
Single Channel, 4-Split, 9-Split, 16-Split
7.3.3 Site List Panel
The site list panel shows registered DVR lists. To connect, Drag & Drop the site.
Before you connect the site, Select the Live or Search mode first in the connection mode panel.
16 different On-Screen DVR, a mixture of different connection modes can be monitored.
