DocuTech 128/155/180 HighLight Color Operator Guide 3-25
Routine maintenance
Figure 3-22 Preparing to add fuser blend
WARNING: Fuser lubricant spills cause the floor to be slippery. If
any fuser lubricant is spilled onto the floor, it must be removed
immediately.
c. Open a new box of fuser lubricant and remove a bottle.
Remove the cap from the bottle of fuser lubricant.
d. Carefully pour the fuser lubricant into the reservoir until the
level reaches the MAX line. Avoid spilling the fuser
lubricant or overfilling the reservoir.
CAUTION: Do not push the fuser lubricant bottle into the
reservoir with excessive force. There is an anti-splash seal in the
reservoir that could be damaged.
To Next Page
