3-26 DocuTech 128/155/180 HighLight Color Operator Guide
Routine maintenance
Figure 3-23 Adding the fuser blend
e. Replace the reservoir cap by turning it clockwise
approximately one full turn. Do not overtighten the cap.
f. Inspect the area around the fuser to ensure no fuser blend
was spilled. Clean as required.
g. Push the fuser blend reservoir in until it stops.
6. Push the fuser drawer in until it latches into place.
Figure 3-24 Closing the fuser drawer
