1. Product Overview
NOTE 1:Throughout this guide, Finisher D, Booklet Finisher D, or
Finisher D2 may be referred to simply as the Finisher.
NOTE 2:Throughout this guide, the Duplex Automatic Document
Feeder is abbreviated as “Document Feeder” or “DADF.”
No. Component Function
27 Post-process inserter
(Cover/Transparency
separator tray) / Tray 8
Load paper for cover or transparency separators. Paper loaded here is
not used for copying.
28 Decurl button For lighter weight paper especially, press this button to decurl the output.
29 Output tray Copies are delivered here when specific output features are selected,
such as Automatic sorting, Collated, Uncollated, or Normal.
30 Finisher tray Receives copies when you select stapled, punched, and Z-folded copies.
31 Booklet output tray Receives copies when you select Bi-Fold or Bi-Fold + Stapling.
32 Booklet output tray button Press this button to deliver and retrieve booklets from the output area.
33 Right cover Open to clear paper jams, replace staples, clear jammed staples, or
remove the scraps from the puncher.
34 Staple cartridges for
booklet
There are two staple cartridge for booklet. Remove this cartridge to
replace staples and clear staple jams.
35 Staple cartridge Contains staples; remove this cartridge to replace staples and clear
staple jams.
36 Punch scrap container Collects the scraps from the puncher. Open to remove the scraps.
37 Tri-Fold output tray
(optional)
Receives copies when you select Tri-Fold In or Tri-Fold out.
38 Tri-Fold output tray button Press this button to open tri-Fold output tray.
39 Left cover. Open this cover to access the machine and to clear paper jams.
40 Staple cartridge storage
space
Staple cartridge for replacement can be stored (D Finisher only).
41 Staple waste container Container for staple waste; remove this cartridge when full (D2 Finisher
only).
