Xerox 4590/4110 Copier/Printer Getting Started
3-10
3. Loading Paper
Load tab paper in trays 3 to 4
1. Pull out the tray towards you until it stops.
WARNING: When pulling out the paper tray, do it slowly. If
pulled out with too much force, the tray can hit and injure your
knees.
2. Load and align the edge of the tab paper against the right
edge of the tray with the side to be copied or printed on facing
down.
3. Move the two paper guide levers while holding their grips so
that they lightly contact the edges of the paper.
Ensure that the levers are positioned correctly.
NOTE: Do not load paper exceeding the maximum fill line. Doing
so might cause paper jams or machine trouble.
MAX
