Folding Styles
Program 185
Message Dimensions Appearance
U1-01
185
a=185mm
b=297mm
Face Up
b
a
Face Down
a
b
Program 185+25
Message Dimensions Appearance
U1-02
185+25
a=185mm
b=297mm
m=25mm
Face Up
a
b
m
Face Down
a
b
m
Program 190
Message Dimensions Appearance
U1-03
190
a=190mm
b=297mm
Face Up
b
a
Face Down
a
b
Program 190+20
Message Dimensions Appearance
U1-04
190+20
a=190mm
b=297mm
m=20mm
Face Up
a
b
m
Face Down
a
b
m
Program 198
Message Dimensions Appearance
U1-05
198
a=198mm
b=297mm
Face Up only
b
a
Program 210
Message Dimensions Appearance
U1-06
210
a=210mm
b=297mm
Face Up
a
b
Face Down
a
b
