Xerox 8830 - DDS User Interface Controls (continued); Navigation and Mode Keys

September 2001 88XX Series Folder Operator Manual 8
SAFETY LEVER
Insures that the bridge door
remains open while removing
media jams.
ON/OFF BUTTO
N
R
ESET BUTTO
N
SAFETY LEVER
Insures that the bridge
remains fixed in the upright
position when lifted
BRIDGE DOOR
Opens to remove media jams.
Unfolded prints are delivered
to the top surface.
OUTPUT BIN
Folded prints are
delivered here
N
ON-FOLDED PRINT DRIV
E
Feeds the print over the bridge
in the no-fold o
p
eration
CONTROL PANEL
Used to select folding
features and diagnostic
Folder Description
111328
