Xerox 8830 - Scanning to the Network (SCAN Mode) (continued); Features Not Available in SCAN Mode; Operating in SCAN Mode for Network Retrieval

September 2001 88XX Series Folder Operator Manual 48
Miscellaneous Information
Specifications
Space Requirement
With 8830/8825 Printer With 8855 Printer
A (Depth) = 2130 mm / 83 ¾ inches
B (Height) = 1030 mm / 40 ½ inches
C (Width) = 1850 mm / 73 inches
A (Depth) = 2610 mm / 102 ¾ inches
B (Height) = 1030 mm / 40 ½ inches
C (Width) = 1850 mm / 73 inches
C
961mm
A
B
A
B
969mm
C
Technical Specification
Voltage Requirements :
− 115 Vac ± 10% (60Hz)
− 230 Vac ± 10% (50Hz)
Power Consumption:
− 4/8 A 50/60Hz
− 0.6 A (standby)
Audible Noise
Impulse Average Continuous
69 dBA max. 65 dBA max. ( run )
NEGLIGIBLE NEGLIGIBLE (stand by)
Environmental
− Relative Humidity : 35% to 85%
− Temperature 60 to 90° Fahrenheit (15.5° to 32 ° Celsius)
Paper
− Bond (ordinary), 18-22lbs (75-100gsm)
Minimum size :
− 8½ inch x 11 inch (US A size)
− 210 mm x 297 mm (European A4 size)
Maximum size :
− 36 inch x 142 inch (US) panel 8 ½”
− 914 mm x 3600 mm (European) panel 210mm
Weight :
− 330 Kg (727 lb.)
Weight :
− 288 Kg (634 lb.)
