September 2001 88XX Series Folder Operator Manual 47
SYMPTOM CAUSE SOLUTION
A2/C size with Title Block folded inside (E-
17).
A. Folder without rotation and IOT without paper
roll 420 (17/18”).
A. Scan A2/C size LEL with Title Block
leading edge and print LEL. Sheet delivered
always Face Down output Landscape.
With the Double Bin configuration, the size
does not fall in the bin 1 even if the operator
selection is Bin 1.
A. The first bin is full.
B. The sizes that exit the Cross Folder in vertical
position (Wallet, Afnor) are always stacked in
the second bin.
A. Empty the first bin.
B. Try to set the work so that the sizes that exit
the Cross Folder in vertical position are
included in the job that has to be stacked in
the second bin.
The folder keeps showing a Folding Method
on the control panel and the system is stopped.
A. Probably a job queue is stopped or waiting to
be sent to the printer.
A. Perform the Suspending the Print Queue
procedure.
