6. Remove the tray.
7. Push the duplex unit latch to open the duplex unit.
8. Remove the jammed paper.
Note: Make sure that all paper fragments are removed.
9. Close the duplex unit.
10. Insert the tray.
PPaappeerr JJaamm iinn tthhee RReeaarr DDoooorr
1. Open the front door.
Warning—Potential Damage: To prevent damage from
electrostatic discharge, touch any exposed metal frame of
the printer before accessing or touching interior areas of
the printer.
2. Remove the imaging unit.
Warning—Potential Damage: Do not expose the imaging
unit to direct light for more than 10 minutes. Extended
exposure to light may cause print quality problems.
Warning—Potential Damage: Do not touch the
photoconductor drum. Doing so may affect the quality of
future print jobs.
17
