Xerox DocuMate 150 User Manual

Scanning
30 DocuMate 150 Scanner User’s Guide
The Advanced Settings Tab
1. Click the Advanced Settings tab.
The options of the Advanced Settings tab are for the Color or
Grayscale scanning mode.
2. Drag the sliders to the left and right to change the color settings. As
you do, the image changes to show the effects of the new settings.
Saturation—the strength or purity of a color.
Hue—the color your eyes see as reflected from the image.
Gamma—controls the brightness of the midtone colors.
3. Click on Apply to save the changes on the Advanced Settings tab.
4. If there are no other settings you want to change, click OK to save the
new configuration.
It will now be in the list of Scan Configurations on the One Touch
Properties window for the appropriate Destination Applications.

Xerox DocuMate 150 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	24 bit
Maximum scan size	216 x 915 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
Maximum duty cycle	75000 pages per month
ISO A-series sizes (A0...A9)	A4
Auto document feeder (ADF) input capacity	50 sheets
Scan media weight	60 - 105 g/m²
Dimensions (WxDxH)	309 x 160 x 141 mm
Standard media sizes	51mm x 64mm (2\
Dimensions (W x D x H) (imperial)	12.1 x 6.3 x 5.5 \
USB version	2.0
Standard interfaces	USB 2.0
Bundled software	Kofax VRS OmniPage Pro Nuance PaperPort
Minimum RAM	512 MB
Minimum processor	Pentium IV
Minimum storage drive space	350 MB
Minimum system requirements	CD/DVD-ROM, USB
Compatible operating systems	Windows 2000 (SP4) / XP (SP2) / Vista

Weight and Dimensions

Depth	160 mm
Width	309 mm
Height	141 mm
Weight	2340 g
