Xerox DocuMate 150 User Manual

Scanning
56 DocuMate 150 Scanner User’s Guide
13. Now click the arrow buttons to select a scanner button for each new
configuration. Click Apply to set that button for that configuration.
The following examples show that buttons 7 and 8 have been set to
scan to each of the new configurations.
Scan to multiple storage folders:
1. Insert the documents you want to scan to storage.
2. Press the Destination Selector buttons on the scanner to get to one
of the buttons set up for scanning to storage.
3. Press the Scan button to scan the documents.
4. When scanning is finished, insert the next set of documents and
press the Destination Selector buttons to get to the next button you
have set up for scanning.
5. Press the Scan button to scan the documents.
When scanning is finished, the documents are stored in the two separate
folders.
The new configurations
apply to the Transfer to
Storage Destination
Application.

Xerox DocuMate 150 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	24 bit
Maximum scan size	216 x 915 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
Maximum duty cycle	75000 pages per month
ISO A-series sizes (A0...A9)	A4
Auto document feeder (ADF) input capacity	50 sheets
Scan media weight	60 - 105 g/m²
Dimensions (WxDxH)	309 x 160 x 141 mm
Standard media sizes	51mm x 64mm (2\
Dimensions (W x D x H) (imperial)	12.1 x 6.3 x 5.5 \
USB version	2.0
Standard interfaces	USB 2.0
Bundled software	Kofax VRS OmniPage Pro Nuance PaperPort
Minimum RAM	512 MB
Minimum processor	Pentium IV
Minimum storage drive space	350 MB
Minimum system requirements	CD/DVD-ROM, USB
Compatible operating systems	Windows 2000 (SP4) / XP (SP2) / Vista

Weight and Dimensions

Depth	160 mm
Width	309 mm
Height	141 mm
Weight	2340 g
