User’s Guide 7
DocuMate 700 Installation
Step 2: Connect the Scanner
1. Remove any tape from the top and side of the scanner.
2. Slide the locking tab, on the side of the scanner, to its unlocked position. The scanner will
not scan when locked.
3. Plug the power supply into the power port on the scanner.
NOTE: Only use the power supply (HEG42-240200-7L made by HiTron) included with your
scanner. Connecting any other type of power supply may damage your scanner, and will void its
warranty.
