User’s Guide 57
DocuMate 700 Scanning from TWAIN
Scanning Part of an Image
To scan part of an image, you draw a box around the part you want. The scanner then only
scans that portion of the image and places it in the scanning application.
1. Put the pointer on the image and drag a box around the section of the image that you
want to scan.
A dotted outline shows the selected area in the image.
You can now move or resize the outline to select the specific area you want to scan.
2. To move the dotted outline, put the pointer in the selected area and drag the mouse.
3. To resize the area, put the pointer on a dotted line and drag.
4. If you want to remove the selected area and start over, click Remove.
5. Click Scan when you’re ready to scan the portion of the image.
The selected scan area. This is the image that appears
on the PaperPort desktop when
scanning is finished.
