Spare Parts List
FaxCentre F110 12/04 5-1
5. Spare Parts List
PL 1 Operation Panel Unit (OPU) ............................................................................................ 5-3
PL 2 Upper Guide Assembly .................................................................................................... 5-4
PL 3 Housing and Scanner ...................................................................................................... 5-5
PL 4 Paper Feeder Assembly .................................................................................................. 5-6
PL 5 Fuser Assembly ............................................................................................................... 5-7
PL 6 Main Board Assembly ...................................................................................................... 5-8
PL 7 Drive Module .................................................................................................................... 5-9
PL 8 Bracket Assembly .......................................................................................................... 5-10
PL 9 Rear Cover Assembly .................................................................................................... 5-11
PL 10 Paper Cassette Assembly ............................................................................................ 5-12
PL 11 Cradle and Handset (220V Only) ................................................................................. 5-13
PL 12 Consumables and Tools .............................................................................................. 5-14
