Spare Parts List
5-4 12/04 FaxCentre F110
PL 2 Upper Guide Assembly
INDEX PART NO COMMENT DESCRIPTION
1,2,5 032N00424
REP 3
RETARD PAD ASSEMBLY
1 019N00815 ADF PAD
2 025N00093 SHEET - READING BAR
3 120N00455 ACTUATOR ADF
4 120N00456 ACTUATOR RP
3
4
5
1
2
