5. To identify the print driver for your printer model, review the list of available print drivers.
Note: For additional information on each driver, click Description.
6. To select the print driver for your printer model and operating system, click its name.
7. To begin the download, read the End User License Agreement, then click accept.
The file automatically downloads to the default location for your computer file downloads.
8. To install the Xerox
®
Print Driver package:
Open the package with your OS package manager.
To install using a command-line utility, change to the directory where you downloaded the
file. To run the installer, type the appropriate command-line utility for your operating system.
For example:
Red Hat: rpm -U <filename>.rpm
Debian-based Linux: dpkg -i <filename>.deb
AIX: rpm -U <filename>.rpm
HPUX: <filename>.depot.gz
Solaris: pkgadd -d <filename>.pkg
Note: Most installations create a Xerox directory in /opt/Xerox/prtsys. For additional
information about utilities included in the OS package manager, refer to the manual included
with the package. For example, man xeroxprtmgr.
Launching Xerox® Printer Manager
To launch Xerox
®
Printer Manager, do one of the following tasks.
For UNIX, log in as root. From a terminal window, type xosdprtmgr, then press Enter or Return.
For Linux, type sudo xeroxprtmgr, then press Enter or Return.
Printing with xeroxprint
Xerox has its own print command. You can use the following command:
xeroxprint -d<Some_Queue> -o[Options] <Somefile>
Printing from a Linux Workstation
To print from a Linux workstation, install either a Xerox
®
print driver for Linux or a CUPS (Common
UNIX Printing System) print driver. You do not need both drivers.
Xerox recommends that you install one of the full-featured custom print drivers for Linux. To locate
drivers for your printer, go to www.xerox.com/drivers.
If you use CUPS, ensure that CUPS is installed and running on your workstation. For instructions to
install and build CUPS, refer to Easy Software Products in the CUPS Software Administrators Manual.
For complete information on CUPS printing capabilities, refer to the CUPS Software Users Manual
available from www.cups.org/documentation.php.
133

Table of Contents

Other manuals for Xerox VersaLink B7130

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xerox VersaLink B7130 and is the answer not in the manual?

Xerox VersaLink B7130 Specifications

General IconGeneral
N-up printing16
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Duplex printing modeAuto
Time to first page (black, normal)5.2 s
Print speed (black, normal quality, A3)17 ppm
Duplex print speed (ISO/IEC 24734, A3) black11 ppm
Print speed (black, normal quality, A4/US Letter)30 ppm
Optional connectivityWireless LAN
Wi-FiNo
Cabling technology10/100/1000Base-T(X)
Security algorithms256-bit AES, FIPS 140-2, IPSec, SNMPv3
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologies@PrintByXerox, Apple AirPrint, Mopria Print Service
Processor cores2
Internal storage capacity320 GB
Sound power level (standby)4.1 dB
Sound power level (printing)6.8 dB
Copier resize25 - 400 %
Maximum copy resolution600 x 600 DPI
Maximum number of copies999 copies
Time to first copy (black, normal)4.3 s
Copy speed (black, normal quality, A4)30 cpm
DisplayLCD
Control typeTouch
Product colorBlue, White
Display diagonal7 \
Market positioningBusiness
AC input voltage220 - 240 V
AC input frequency50 Hz
Power consumption (max)480 W
Power consumption (sleep)0.4 W
Power consumption (standby)94 W
Mac operating systems supportedMac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey
Other operating systems supportedHP-UX 11, HP-UX 11.11, HP-UX 11.23, HP-UX 11.31, IBM AIX 5.3, IBM AIX 6.1, IBM AIX 7.1, IBM AIX 7.2, Solaris 10, Solaris 10 SPARC, Solaris 11, Solaris 11 SPARC, Solaris 8, Solaris 9, Solaris 9 SPARC
Server operating systems supportedWindows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supportedWindows 10, Windows 11, Windows 7, Windows 8, Windows 8.1
Scan toE-mail, USB
Scan driversTWAIN, WIA
Scanner typeFlatbed & ADF scanner
Maximum scan area297 x 431.8 mm
Output color depth24 bit
Output grayscale depth8 bit
Image formats supportedJPG, TIFF
Document formats supportedPDF
Storage temperature (T-T)0 - 35 °C
Operating temperature (T-T)10 - 32 °C
Operating relative humidity (H-H)10 - 85 %
Faxing-
PCL fonts83
Printer fontsPCL, PostScript
Printing colorsBlack
Duplex functionsCopy, Print, Scan
Maximum duty cycle129000 pages per month
Number of PostScript fonts136
Number of print cartridges1
Page description languagesHP-GL, JPEG, PCL 5, PCL 6, TIFF, XPS
Total input capacity620 sheets
Total output capacity250 sheets
Paper tray 1 input capacity520 sheets
Multi-Purpose tray input capacity100 sheets
Auto document feeder (ADF) input capacity130 sheets
Custom media width139.7 - 297 mm
Custom media length182 - 431.8 mm
Duplex media weight60 - 169 g/m²
Paper tray media typesBond paper, Card stock, Glossy paper, Heavy paper, Heavy printing media, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight60 - 256 g/m²
ISO A-series sizes (A0...A9)A3, A4, A5
Multi-purpose tray media typesBond paper, Envelopes, Glossy paper, Heavyweight paper, Labels, Letterhead, Plain paper, Preprinted forms, Recycled paper
Maximum ISO A-series paper sizeA3
Multi-Purpose Tray media weight60 - 216 g/m²
Auto Document Feeder (ADF) media weight38 - 128 g/m²
Current rating12 A
Browser supportedMicrosoft, Internet Explorer, Microsoft Edge, Mozilla Firefox, Apple Safari, Google Chrome
Languages supportMulti
Supported network protocolsTCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD LDAP Bonjour/AirPrint FTP
Weight and Dimensions IconWeight and Dimensions
Depth670.8 mm
Width615.7 mm
Height766.5 mm
